Scaffolding
Ringlock Scaffolding
CE & RoHS certified modular ringlock system with rosette connections for fast, safe erection on complex façades and infrastructure works.
Overview
Our ringlock system uses a forged rosette that accepts up to eight connections at once, giving fast, square, positively-locked assembly. The ringlock line carries CE certification and RoHS reports, backed by third-party testing.
Key Benefits
Why This System
◆
Fast Erection
Up to 8 connections per rosette — squares itself as you build.
◆
CE Certified
Third-party certified for the European market.
◆
Hot-Dip Galvanised
Full-immersion coating for long outdoor service life.
◆
Access or Shoring
One system serves façade access and vertical shoring.
Specification
Technical Data
| Standard Material | Q345B steel |
|---|---|
| Rosette | Forged, 8-hole |
| Surface | Hot-dip galvanised, 65–86 μm |
| Standard Lengths | 0.5 / 1.0 / 1.5 / 2.0 / 3.0 m |
| Ledger Lengths | 0.6 / 0.9 / 1.2 / 1.5 / 1.8 / 2.4 m |
| Load Capacity | up to 40 kN per standard |
| Certification | CE certified, RoHS reported |
Gallery
Product Images
Need a Quote for Ringlock Scaffolding?
Tell us the quantity, the structure and your timeline. We will come back within one business day with pricing and lead time.
