Roof Plate Support (EB Early-Stripping Head / Slab Support Head, EB300～EB700 Series)

Item K(WxH) Weight (kg)
EB300 1.75
EB400 2.10
EB500 2.60
EB600 3.00
EB700 3.30


Model Specifications:
EB300, EB400, EB500, EB600, EB700
Product Description
EB support head is the core component of aluminum formwork early stripping system. The numeric code indicates applicable supporting spacing. Its bottom end inserts onto the top of vertical steel props, while the top bears floor formwork and K-plate, which is essential to realize early slab stripping. After concrete gains stripping strength, only floor aluminum panels are removed; steel props together with EB heads remain loaded, shortening idle period of formwork.
Construction Advantages
Early stripping allows slab formwork removal 3~7 days in advance for rapid turnover to upper floors, cutting total formwork investment of projects.
Integrally forged aluminum body features high load capacity and stable bearing performance to avoid deflection or camber deformation of cast-in-place slabs.
Full range from EB300 to EB700 fits slab supporting demands of various bay sizes and load conditions.
Weight Reference
EB300: 1.75kg｜EB700: 3.30kg
