Beam & Top Angle (SC Beam-Column Angle Aluminium / External Corner Connector)

Item SC(WxH) Weight (kg)
100X100 SC 250+250 2.40
150X150 SC 250+250 2.50
100X100 SC400+400 3.95
150X150 SC 400+400 4.10

Specifications:
100×100 SC250+250, 150×150 SC250+250, 100×100 SC400+400, 150×150 SC400+400
Product Description
SC angle aluminium is L-shaped extruded profile. The codes 100×100 / 150×150 refer to groove width of the bent corner; 250+250 / 400+400 denote the leg length on both sides of the angle. It is specially used for external corners at joints of beam bottom and beam side panels, as well as connection nodes between columns and primary & secondary beams as a shaped corner connecting component.
Construction Advantages
Standard L-shaped profile ensures sharp, neat concrete corners at beam-column joints, eliminating messy panel joints and slurry leakage risks at node positions.
Uniform pitch of pre-drilled holes allows interchangeable standard pins for fast on-site assembly and cuts consumption of custom-made scattered formwork pieces.
Two leg-length options (250 and 400) match small secondary beams and large main beams respectively, compatible with most beam dimensions in residential construction.
Weight Reference
100×100 SC250+250: 2.40kg｜150×150 SC400+400: 4.10kg
